Characteristics
1.Digital displaying of temperature, humidity and turning frequency
2.Full automatically temperature controlling
3.Full automatically humidity controlling
4.Full automatically eggs turning
5.Full automatically alarming
6.Full automatically cooling and ventilator
7.Back emergency system
8.Microcomputer, completely automatic incubator
9.Hatching rate more than 98%
Product Details
Name |
Egg Capacity (pcs) |
Model Number |
ZH-1408 |
Chicken(Pigeon) egg |
1408 |
Duck (Peacock) egg |
1008 |
Goose( Wild goose)egg |
512 |
Quail egg |
3536 |
Ostrich egg |
36 |
Power(w) |
240 |
Size |
1.0*0.71*1.56 M |
Volume |
1.11CBM |
Temperature control accuracy |
±0.1°C |
Moisture control accuracy |
±5%RH |
Hatching rate |
high more than 96% |
MOQ |
1 SET |
Delivery time |
Within 3 days |
Place of Origin |
Shandong, China (Mainland) |
Lifetime |
10 - 12 Years |
Warranty |
3 years |
Package |
Wooden case with high quality |
Main Technical Parameters of Poultry Incubator Hatcher
1. Range of temperature display: 5~50°C
2. Precision of Temperature control: ±0.1°C
3. Range of humidity display: 0—99%RH
4. Precision of humidity display: 1%RH
5. QTY of output circuit: 7 (overheat,heat control,low temperature,egg turning in left & right direction,humidity control,alarm)
6. output current: heat control,low temperature in 10A, others in 1A
7. Times of egg turning: Max record is 999 times.
8. Period of egg turning: adjustable between 0.1 and 99.9 hours (Fixed in 1.5 hours when delivery)
9. Time of egg turning: adjustable between 1 and 255 seconds (fixed in 180 seconds when delivery)
10. Period of ventilation: adjustable between 5 and 999 minutes (Fixed in zero when delivery, no ventilation)
11. Time of ventilation: adjustable between 0 and 999 second(Fixedin 30 second when delivery)
Using Your Egg Incubator
1.Put water into the tray before use , the water level must be higher than the heater
2.Put the eggs on the egg tray
3.Plug in power
4.Temperature and humidity setting (Chicken eggs need 21days ,first 18days Temperature is 38°C and Humidity is 60RH ;last 3days the temperature is the same and the humidity is 70RH )
5.Factory setting :Reference temperature & humidity :38°C& 60%RH
Cycle of Egg-turning :90-minute
Time of Egg-turning :180 seconds
Ventilation cycle :120 minutes
Ventilation time :30 seconds
Full technology and function
1. Automatic turning system tilting the eggs 45° Once per two hours. According your actual request, you can set turning interval time you need.
2. Big middle fan with automatic heating and roller humidifying system.
3. Backup emergency and alarming system for insurance using.
4. Automatic air cooling system and automatic ventilator.
5. Inside light.
6. Made of polyester, double wall construction for a perfect insulation.
7. Trolley egg-frame for easy operating, inside disinfecting and cleaning.
Packing:High quality wooden case with foam inside, edge with iron around.
The packing is thick and strong which can make sure the incubator is safe over the transportion process.
Shipping:We usually ship the incubators by sea, after received your payment, we will place an order to factory, when the incubators have finished made,we will arrange the shipment as soon as possible.
Normal model incubator machine
In machine with 16pcs egg trays & 1pcs hatcher box
New model: setter and hatcher combined machine
In machine with 16pcs egg trays & 16pcs hatcher boxes
(Note:If you need to buy setter and hatcher combined machine, you need to inform the salesperson. If you don't, we will send the common model by default.)
Advantages compared with the old incubator:
1.This is an updated version of the incubator, there are two functions of the incubator : hatcher, brooder. So you don't need additional hatcher .
2.The space increased, this is good for the air flow in the equipment, make temperature more uniform , enhance the hatching rate.
3.Because of the hatching basket protection,the machine avoids the death of a newborn chick when it falls off the egg tray and cannot be taken out in time.
4.The chicks can stay in the machine for a long time, so the chicks will be more healthy and increase the survival rate.
Other product we produce:
Industrial incubator capacity from 88~50688 eggs
Mini incubator model: ZH-8 , ZH-12, ZH-15, ZH-24, ZH-32, ZH-36, ZH-48, ZH-56, ZH-60, ZH-72, ZH-96, ZH-112, ZH-154
Plucker model: ZH-30, ZH-40, ZH-50, ZH-60, ZH-65, ZH-80
Poultry scalder:70L, 120L
Plastic product:Transport crates,poultry feeder &drinker,etc .
We guarantee that all the main parts of each incubator will be used for 3 years, and we will provide the following spare parts (including egg tester, heating tube, humidification tube, operation manual, etc.) with the machine for free, and provide some accessories for you according to your actual needs. If you have any questions about this machine, you can contact the sales manager.
As the leading egg incubator factory in China, we have over 10 years history. Our products have been exported to all over the world and enjoyed a good reputation with best quality, good package and great after-sale service.
We produce the egg incubator capacity from 8 eggs to 50688 eggs, all the egg incubators are fully automatic, full automatically eggs turning, full automatically temperature and humidity controlling. We also produce some incubator relative product such as poultry plucker, poultry scalder, all kinds of controller, heating and humidity tube, feeder, drinker, spray bottle, egg tester, egg tray , etc.
Due to the high volume production, we could give you the best price than other small factories. we will give you the best quality and the lowest price. If you have chance to come to China, welcome to our factory.
Q: When the incubator is working, do we need to operate by hands ?
A: No, the incubator is full automatically egg-turning, full automatically temperature and humidity ventilation control.
Q: What should we do if there have problems during use ?
A: We have 3 years warranty period, any problems you have, welcome to contact me! We will provide our best professional service for you.
Q: There are many kinds of incubators, I don't know how to choose?
A: Welcome to contact me, I will according to your demands give you best suggestion. If I'm outline, please send e-mail to me, you can also add me on wechat. I will reply to you in 24 hours.
